FG-007

Wheel Specification — FG-007

Size	Product No.	Inset (mm)	Outset (mm)	Disc Thickness (mm)	Bolt Holes	P.C.D (mm)	Bolt Hole Dia (mm)	C.B.D (mm)	Max Load (Kg)	Weight (Kg)	Valve	Tire
19.5×6.00	S0031655	116	135	19	245	245	Ø16	Ø225	1800	15.7	TR554D	8R19.5
19.5×6.75	S0031655	115	136	21	222.25	222.25	Ø32.5SR22	Ø164	2500	17.1	TR554D	225/70 R19.5
19.5×6.75		120	141	21	275	275	Ø26	Ø221	2750	16.5	TR554D	225/70 R19.5
19.5×6.75	S0031660	126	147	21	285	285	Ø32.5SR22	Ø221.2	2500	16.7	TR554D	225/70 R19.5
19.5×7.50		125.5	147.5	22	275	275	Ø32	Ø221	3000	18	70MS-7	245/70 R19.5
19.5×7.50		134	156	22	275	275	Ø32	Ø221	3000	17.9	TR554D	245/70 R19.5
19.5×7.50	S0012275	95	116	21	275	275	Ø24	Ø221	3000	16.7	TR554D	245/70 R19.5
